WINDOW TINT
KDX Window Film is committed to providing premium film solutions based on High-Performance Optical Film materials. KDX Window Film is one of the Largest manufacturers of Window Film in Asia. While focusing on Global business, Development and Operation, KDX is dedicated to the Development, Production and Sales of High-Performance Optical Film such as Automotive, Architectural Window Film, Safety and Security film, and Paint Protection Film
ENHANCED
PRIVACY
HEAT
REJECTION
COLOR
STABLE
MANUFACTURED
WARRANTY
TECHINICAL
DEFINITION
01
VISIBLE LIGHT TRANSMISSION (VLT)
​This is the ratio of the human eye-weighted average daylight that is transmitted through the window to that which hits the window.
02
VISIBLE LIGHT REFLECTION (VLR)
Visible light is defined as that portion of the solar energy spectrum under average daylight conditions that is visible to the human eye, and the values given are based on the response of the human eye. The ratio of that which is reflected away from the surface of the window to that which strikes it is called the percent of visible light reflected.
03
​UV REJECTION (UVR)
This is the ratio to the difference in ultraviolet transmission of the glass before and after installing film. It is expressed as a percentage and is determined by the respective UV Transmission values in the glass with and without film.
04
TOTAL SOLAR ENERGY REJECTION (TSER)
This is a measure of how much solar energy (like heat from the sun) is blocked by the film on the glass compared to how much comes through the glass without the film. It’s expressed as a percentage, and it's calculated based on how much the film reduces the amount of sunlight and heat that passes through the glass
KING
SERIES
Our King series is a 3.0mil/2-ply color stable film. Construct with a sputtering technology, this film does not interfere radio or GPS signals while providing a 54% TSER (70% VLT).
•Non-Reflective
• Up to 69% of Heat Rejection
•Up to 99% of UV Rejection
•Enhanced Privacy
•Anti Scratch Top Coat
Products | VLT (%) | VLR (%) | UVR (%) | TSER (%) | IRR (900-1000nm) (%) | IRER (780-2500nm) (%) | SOLAR A (%) | THICKNESS (Mil) |
|---|---|---|---|---|---|---|---|---|
S70 | 70 | 11 | >99 | 54 | 83 | 81 | 17 | 3.0 |
S55 | 56 | 9 | >99 | 54 | 78 | 79 | 23 | 3.0 |
S40 | 40 | 6 | >99 | 60 | 80 | 77 | 31 | 3.0 |
S30 | 30 | 7 | >99 | 65 | 80 | 75 | 38 | 3.0 |
S15 | 15 | 6 | >99 | 69 | 79 | 80 | 46 | 3.0 |
CERAMIC
SERIES
Our ceramic series is a 2.0 mil/2-ply color stable film with a lifetime warranty. This non-metal film provides supreme heat rejection rate up to 69% and does not interfere radio or GPS signals.
• Multi-Directional
• Non-reflective
• Up to 71% of Heat Rejection
• Up to 99% of UV Rejection
• Up to 88% of IR Rejection
• Enhanced Privacy
• Anti-scratch Top Coat
Products | VLT (%) | VLR (%) | UVR (%) | TSER (%) | IRR (900-1000nm) (%) | IRER (780-2500nm) (%) | THICKNESS (Mil) |
|---|---|---|---|---|---|---|---|
STELLAR 80 | 80 | 10 | >99 | 28 | 61 | 34 | 2.0 |
STELLAR 70 | 70 | 9 | >99 | 44 | 88 | 66 | 2.0 |
STELLAR 50 | 49 | 8 | >99 | 53 | 90 | 67 | 2.0 |
STELLAR 35 | 34 | 8 | >99 | 59 | 90 | 68 | 2.0 |
STELLAR 20 | 20 | 8 | >99 | 62 | 88 | 64 | 2.0 |
STELLAR 05 | 05 | 8 | >99 | 71 | 88 | 67 | 2.0 |
CARBON IR
SERIES
Our Carbon IR series is a 1.5 mil/2-ply color stable film with a lifetime warranty. This film does not interfere radio or GPS signals while providing a TSER up to 58%.
• Non-reflective
• Up to 58% of Heat Rejection
• Up to 99% of UV Rejection
• Up to 90% of IR Rejection (900-1000nm)
• Enhanced Privacy • Anti-scratch Top Coat
Products | VLT (%) | VLR (%) | UVR (%) | TSER (%) | IRR (900-1000nm) (%) | IRER (780-2500nm) (%) | THICKNESS (Mil) |
|---|---|---|---|---|---|---|---|
COSMIC IR 50 | 49 | 7 | >99 | 42 | 86 | 47 | 1.5 |
COSMIC IR 35 | 35 | 7 | >99 | 46 | 87 | 53 | 1.5 |
COSMIC IR 20 | 20 | 7 | >99 | 52 | 88 | 63 | 1.5 |
COSMIC IR 15 | 14 | 6 | >99 | 54 | 89 | 68 | 1.5 |
COSMIC IR 05 | 7 | 6 | >99 | 58 | 90 | 86 | 1.5 |
NOVA CARBON
SERIES
Our Carbon Series is 1.5 mil/2-ply color stable film with a lifetime warranty. This series provides privacy and outstanding heat rejection.
• Non-reflective
• Up to 57% of Heat Rejection
• Up to 99% of UV Rejection
• Enhanced Privacy
• Anti-scratch Top Coat
• Easy to shrink and dry quickly
Products | VLT (%) | VLR (%) | UVR (%) | TSER (%) | IRR (900-1000nm) (%) | IRER (780-2500nm) (%) | THICKNESS (Mil) |
|---|---|---|---|---|---|---|---|
NOVA 47 | 47 | 7 | >99 | 32 | 22 | 19 | 1.5 |
NOVA 35 | 35 | 7 | >99 | 41 | 35 | 22 | 1.5 |
NOVA 20 | 20 | 7 | >99 | 50 | 56 | 36 | 1.5 |
NOVA 15 | 6 | 6 | >99 | 52 | 58 | 38 | 1.5 |
NOVA 05 | 6 | 6 | >99 | 57 | 72 | 50 | 1.5 |
